T-Posts
T-Posts
Heavy-duty studded steel T-posts for agricultural fencing
- Profile
- T-section (studded)
- Material
- Hot-rolled Steel
- Length
- 5' to 10' (1.5-3.0m)
- Weight
- 1.25 lb/ft to 2.0 lb/ft
- Finish
- Green Painted / Galvanized
Product Description
WANSUN T-Posts are hot-rolled steel posts with a T-shaped cross-section and stud anchors along the web. The studs securely hold wire fencing at proper spacing without clips. T-posts are the standard choice for agricultural fencing, offering easy installation with a post driver and excellent strength-to-weight ratio. Available in green painted and galvanized finishes.
Full Specifications
| Material | Q235 hot-rolled steel |
|---|---|
| Cross-Section | T-profile (flange + web) |
| Length | 1.5m (5'), 1.65m (5.5'), 1.8m (6'), 2.1m (7'), 2.4m (8'), 3.0m (10') |
| Weight per Foot | 1.25 lb/ft, 1.33 lb/ft, 1.5 lb/ft, 1.75 lb/ft |
| Stud Type | Anchor studs (standard), spaced 2" apart |
| Stud Count | Varies by length (approximately 2 studs per 6cm) |
| Surface Finish | Green painted (standard), Galvanized (HDG) |
| Paint Coating | Electrostatic powder coating, 60-80 microns |
| Zinc Coating (HDG) | 60-100 microns |
| Yield Strength | 235 MPa minimum |
| Tensile Strength | 370-500 MPa |
| Anchored Plate | Spade plate at bottom (150-200mm from tip) |
Key Features
No-Clip Installation
Studded anchors hold wire fencing without separate clips, saving time and materials.
Easy Driving
Tapered tip and spade plate allow easy driving with a manual post driver.
Dual Finish Options
Green painted (standard) or hot-dipped galvanized for maximum corrosion protection.
High Strength
T-profile geometry provides superior bending resistance compared to round posts.
Applications
Livestock Fencing
Farm & Ranch
Property Boundary
Temporary Fencing
Frequently Asked Questions
How deep should T-posts be driven into the ground?
T-posts should be driven to a depth of 45-60cm (18-24") for standard fencing. In loose or sandy soil, drive deeper (60-75cm). The spade plate should be fully below ground level to provide maximum lateral stability.
What weight T-post do I need?
For cattle and livestock fencing, 1.33 lb/ft (2.0 kg/m) posts are standard. For heavy-duty or high-tensile fencing, use 1.5-1.75 lb/ft (2.2-2.6 kg/m). For garden and light fencing, 1.25 lb/ft (1.9 kg/m) is sufficient.
Do I need a post driver to install T-posts?
Yes, a manual post driver (slide hammer) is the standard tool for T-post installation. For large projects, hydraulic post drivers can be used. The tapered tip and spade plate allow the post to be driven with moderate force.
Can T-posts be reused?
Yes, T-posts can be extracted and reused multiple times. Use a post puller or lever tool to extract. Green painted posts may show paint wear after extraction but remain structurally sound. Galvanized posts maintain better appearance through multiple installations.
